CM07 LED Canopy Light 120V-277V(54W) - Caster Lighting
CM07 LED Canopy Light 120V-277V(54W)
CM07 LED Canopy Light 120V-277V(54W)
◆ Die-cast aluminum housing for durability and heat dissipation.
◆ Multiple installation options (conduit/ pendant/ junction box).
◆ Long lifespan of 50,000 hours at 40°C.
-
INFORMATION
Quick to install and pay for itself. the LED Canopy ,DLC - CM07 is an economical retrofit solution for 70-150W HID garage and canopy luminaires, offered in three wattages.
-
SPECIFICATION
ITEM WATTAGE Wattage (Selectable) CCT (Selectable) Lumens Efficacy (lm/W) Surge Protection Input Voltage CRI Dimming Operating Temp. Power Factor Mounting CM07 27W N/A 3K/4K/5K (N) 3603 133 4KV 120-277V >70 0-10V -40~40°C >0.9 Ceiling/Pendant/Conduit CM07 38W N/A 3K/4K/5K (N) 5050 132 4KV 120-277V >70 0-10V -40~40°C >0.9 Ceiling/Pendant/Conduit CM07 54W N/A 3K/4K/5K (N) 7126 131 4KV 120-277V >70 0-10V -40~40°C >0.9 Ceiling/Pendant/Conduit Application
● Parking Garages ● Warehouses ● Work Shop
● Garages ● Storefronts ● Vestibules
-
